2PC Ball Valve 1000 WOG Mounting Pad

1000PSI / PN16~PN63
1/4″~4″ (8mm~100mm)
WCB, S.S.304, S.S.316



get a quote

2PC Ball Valve 1000WOG Mounting Pad Descriptions

2pc ball valve 1000WOG mounting pad ISO 5211 is normally used with pneumatic actuator and electric actuator in the automatic control system. 2pc ball valve 1000WOG direct mounting pad can be divided into 2pc ball valve stainless steel 304(CF8), 316(CF8M) and 2pc ball valve carbon steel (WCB) according to valve materials with pressure of 1000psi. The 2pc ball valve 1000WOG mounting pad lever can be with locking device as optional. Flowspec Luokai can manufacture and supply the 2pc ball valve 1000WOG mounting pad in accordance with ASME B16.34 with sizes of 1/4″~4″ (DN8~DN100mm). Just feel free to contact us now to get best prices. 30 years of experience. High quality. Big stock. Fast delivery.

1. FEATURES

  • Full port
  • Fully opening or closing
  • Blow-out proof stem, reliable sealing
  • Two pieces structure, easy operation and maintenance
  • PED97/23/EC (CE0035) approved
  • Investment casting approved to AD2000-WO certificate

3. STANDARDS

  • Design & manufacturing: ASME B16.34
  • Female threaded x female threaded: G, NPT, PT, Rp, Rc (ASME B1.20.1, BS21/2799, DIN2999/259, ISO228-1, JIS B 0203, ISO7/1)
  • Inspection & testing: API598, EN12266, DIN3230/3

2. TECHNICAL SPECIFICATIONS

  • 1000PSI / PN16~PN63
  • Size: 1/4″~4″ (DN8~DN100mm)
  • Materials: steel (WCB), stainless steel 304(CF8), stainless steel 316(CF8M)
  • Applicable medium: water, oil, gas, corrosive liquids
  • Applicable temperature: -29℃~+120℃ (higher temperature is available upon request)

4. APPLICATIONS

  • Water plant
  • Water supply piping system
  • HVAC
  • Chemical industry
  • Oil & gas
  • Water treatment plant
  • Food & beverage
  • Textile
